DAX 125 2026

  • RRP:
    £3,899.00OTR

Model Specification


Model Description


Which is why the Dax is back. Born in the late 1960s, all the things that made it so good then – small size, easy-going engine and light steering – make it even more enjoyable today.

Real Retro Charm

Why is the Dax, called the Dax you might ask? It’s because its T-shaped pressed-steel mainframe looks rather like a Dachshund dog. Constructed with 21st century engineering know-how it’s both sturdy and stylish. All the other parts are perfect in period detail; the high mini-ape handlebars, off-road-inspired upswept exhaust muffler and dual seat all give the Dax its unmistakable, charming form.

Uncomplicated Riding Pleasure

The Dax is for everybody. So we’ve made it easy to ride. Starting with a seat height of just 775mm and natural control from a relaxed, upright riding position. High-quality suspension – 31mm USD front forks and twin rear shocks – provide a plush ride, as do fat front and rear tyres, which grip well on a variety of surfaces. For peace of mind, single-channel ABS controls braking force to the hydraulic front and rear calipers.

Robust and Efficient Riding

Built for durability and smooth delivery. The air-cooled, 124cc engine with 10.8Nm torque provides lively around-town acceleration and a realistic, two-up cruising speed of 90km/h. It also sips fuel, at 63.7km/l (WMTC mode). To make life even more straightforward, a centrifugal clutch does away with a clutch lever – just open the throttle and go. Shifting through all four gears is via the foot lever, but the system does all the work./p>

Model Specification


  • Engine

    Engine Type

    Air-cooled OHC 4-stroke 2-valve

    Engine Displacement

    124cc

    Bore and Stroke

    50.0 x 63.1 mm

    Carburation

    PGM-FI electronic fuel injection

    Compression Ratio

    10

    Ignition

    Starter

    Electric

    Oil Capacity

    1.0 L

  • Performance

    Max Torque

    10.8 Nm / 5,000 rpm

    Max Power

    6.9 kW / 7,000 rpm

  • Dimensions

    Length x Width x Height

    1,760 x 760 x 1,020 mm

    Wheelbase

    1,200 mm

    Ground Clearance

    180 mm

    Seat Height

    775 mm

    Fuel Capacity

    3.8 L

    Tyres Front

    120/70-12M/C 51L

    Tyres Rear

    130/70-12M/C 56L

    Brakes Front

    Single 220mm hydraulic disc with IMU-based ABS

    Brakes Rear

    Single 190mm hydraulic disc

    Dimensions

    Kerb Weight

    107 kg

    Dry Weight

  • Wheels

    Suspension Front

    Telescopic 31mm USD fork, 100mm axle travel

    Suspension Rear

    Twin shock, 120mm axle travel

    Wheels Front

    5-spoke cast aluminium 12 X MT2.75

    Wheels Rear

    5-spoke cast aluminium 12 X MT3.50

  • Transmission

    Transmission

    4 speed rotary

    Gearbox

    Final Drive

    Chain

    Transmission Type

  • Frame

    Frame Type

    Press backbone frame
