Model Specification
Model Description
Where to? Your choice. The compact, versatile new NX500 delivers city agility and off-road ability. It’s comfortable too, with an aggressive rally-style fairing and large screen for wind protection. E-Clutch adds smooth, clutch-free shifting for effortless control. High-spec tech includes a 5-inch TFT display with Honda RoadSync, while the A2-compliant twin-cylinder engine offers flexible, enjoyable performance with HSTC traction management. The adventure begins.
Next level riding, now with E-Clutch
Unique to Honda, E-Clutch takes riding to the next level. Choose manual clutch control of the six-speed gearbox, or activate E-Clutch via the TFT screen and ignore the lever. That’s it. From pulling away to shifting and stopping, just use the gear lever – E-Clutch handles the rest, smoothly and instantly, like a pro. You can’t stall. Traffic’s easier. And if you want to use the clutch? Go right ahead.
Go short. Go long.
Go where you choose. Effortlessly at home in the city but built for adventure, the rugged NX500 blends a tough off-road silhouette with modern off-road-inspired design. Long-travel suspension absorbs the urban rough and tumble just as it does gravel trails helped by lightweight wheels. The 17.7L fuel tank holds plenty of range. And a relaxed riding position – and natural control of wide handlebars – are matched to an aerodynamic package that neatly channels airflow.
Model Specification
-
Engine
Engine Type
Liquid-cooled 4-stroke DOHC parallel twin
Engine Displacement
471 cc
Bore and Stroke
67 mm x 66.8 mm
Carburation
PGM FI electronic fuel injection
Compression Ratio
10.7
Ignition
Starter
E-Starter
Oil Capacity
3.1 L
-
Performance
Max Torque
43 Nm at 6,500 rpm
Max Power
35 kw (47hp) at 8,500 rpm
-
Dimensions
Length x Width x Height
2,165 mm x 83 0mm x 1,415 mm
Wheelbase
1,445 mm
Ground Clearance
180 mm
Seat Height
830 mm
Fuel Capacity
17.5 L
Tyres Front
110/80R19M/C (59H)
Tyres Rear
160/60R17M/C (69H)
Brakes Front
Dual 296 mm x 4 mm disc with Nissin axial mounted two piston calipers
Brakes Rear
Single 240 mm x 5 mm disc with single piston caliper
Dimensions
Kerb Weight
199 kg
Dry Weight
-
Wheels
Suspension Front
Showa 41 mm SFF-BP USD forks
Suspension Rear
Prolink mono with 5 stage preload adjuster, steel hollow cross swingarm
Wheels Front
19M/C X MT2.5 5Y-Spoke Cast Aluminium
Wheels Rear
17M/C X MT4.5 5Y-Spoke Cast Aluminium
-
Transmission
Transmission
6-speed
Gearbox
Final Drive
Chain
Transmission Type
-
Frame
Frame Type
Steel diamond
